FULLY AUTOMATIC FLAT BED PRINTING MACHINE

(1) Fully Automatic Flat Bed Printing Machine

• Double Servo System and Hydraulic Lifting System Operated
• Structure wise type of the Machine by Default Color Coated (i.e. Channels, Legs, Tiebar, Distances Piece, Angles & Dryer Chambers, Panels Powder Coated Etc.)

MECHAZONIX INDUSTIRES REGULAR STRUCTURE

FEEDING SYSTEM

• Auto Feeding
• Motorised Feeding (Auto) Suitable for All Kind of Fabric Feeding

MAIN CHANNEL

• Machined and Out of C.I.

ROLL

• Main Roll 300mm dia with clutch & bearing padestere
• 300 mm dia Dummy Roll with complete asembly

SUPPORTING CHANNELS FOR PLAY

• Completely Machined Provided with Extra Stiffeners to Enable Extra Ordinary Print Levling.

MACHINE LEGS

• Heavy Duty of 28 / 30 / 32 Kgs. C.I. Casting (Approx) Having Machined all Over.

MACHINE LEGS

• Printing Width : (i) 48" P.W (ii) 60" P.W. (iii) 72" P.W. and Customized (iv) 80 (v) 100 (vi) 110
• Plywood of Table : (i) Wooden Ply (Water Resistance)
• Blanket Tightening Wall & Rail (BTD) Made of Thick CI Plate
• Blanket Tightening Wall & Main Roll Made of Thick Seamless Pipe Ebonite Coated
• Blanket Motion Powered by Double Servo Motor with Encoder & Power Cable
• Repeat Setting Starts from 450mm to Customised.
